Configuring emergency operation (PtMP and PtP connections)
Emergencyoperationisnotconfiguredasafactorydefaultfeature.Aslideswitchislocatedonthebottomof
the system telephone that can be used for configuring emergency operation.
To configure the emergency operation feature, slide the switch on the left side on thebottom of thephone
down. To de-activate emergency operation, slide the switch back to the top position.
Attention: Before you move the emergency operation switch unplug the ISDN connector for
the system telephone. Use a non-metallic tool to move the switch.
Configuring emergency operation at a point-to-point (PtP) connection
IfyouwishtoalsouseyoursystemtelephoneforemergencyoperationataPtPconnectionyoumustalsoac
-
tivatethisfeatureusingthePCconfigurationforyoursystemtelephone. Youcanusetheconfigurationpro
-
gram to set emergency operation at a PtP connection.
Making calls during emergency operation at a point-to-multipoint connection
The system telephone beginsemergencyoperation whenpower supply for thePABX system and theNT is
lost.Emergencyoperation,followedbyatelephonesymbolisthenshowninthesystemtelephonedisplay.
Ifthe230VACpowersupplyisrestoredduringanongoingcall,allnormal,configuredfunctionsareavaila
-
bleagainonly after you hangupthehandset. If the 230V~ powersupply is restored when the handset is in
thecradle, the emergencyoperation display isreplacedby thenormaldisplay whenthehandset islifted,or
on the next call.
Making calls at emergency power supply mode on a point-to-point connection
During emergency power supply mode at a point-to-point connection, you will see the normal operation
displays.
CS410
ThissystemtelephoneisdesignedforconnectiontoaninternalS0-port (4wires)ofan pabxsystem. Ifyou
wish to connect the telephone to an internal Up0-port, be sure to install the internal Up0/S0-module into
the telephone or use the external Up0/S0-converter.
CS410-U
Thissystemtelephoneisdesignedforconnectionto aninternal Up0-port(2 wires)ofan pabxsystem. The
internal Up0/S0-module or the external Up0/S0-converter is then no longer required.
elmeg IP-S400
ConnectthissystemtelephonetothecorrespondingLANport(ornetwork)ofthePABXsystemusingaCat.
5cable.ThesystemtelephoneisequippedwithaPCoutputthatcanbeusedtoconnectotherIPterminalde
-
vices.
Setting up/ Configuring the system telephone
On the system telephone itself you can only carry out a limited configuration of the supported features. A
fullconfigurationisonlypossiblewithanelmeg telephonesystemusingtheprofessionalWINtoolconfigu
-
rator via the corresponding system telephone interface.
Description and installation
2
