LED functions
Function key / LED lit flashes flickers
Line key
Chef-sec-Tasten
Connection Connection on hold Incoming call
Xfer secretary Calls are rerouted from the boss
phone to the secretary.
System parked inquiriy Conversation held in a sys
-
tem-parked inquiry
Extension key Connection Connection on hold Incoming call / Call waiting
Team key Incoming call
Trunk group button no B-channel available Incoming call
Extension key AM Connection with AM/ Voice
Box
AM holds active connection
with caller
Incoming answering machine
call
Voice Mail key New messages available
Function key / LED lit not lit
MSN assignment connection established by means of the
key
Team function log-on/log-off logged in logged out
Day/ night mode Night active day active
Announcement own message
Message enable on/off enabled inhibited
Intercom own intercom
intercom enable on/off enabled inhibited
Call filter active off
Call rerouting active not active
Direct dial-in active not active
Headset on/off Connection or
connection establishment
no connection
Status info button (01) Connection active no WAN connection
Auto-Answer active not active
Userecall flash button modified number default number
Function key /
LED
lit flashes flickers not lit
Connection keys Existing connection Connection being put on
hold
Call status No connection
Each function key with automatic LED functions (e. g. extension keys, line keys) may only be
programmed one time for each system (telephone and key expansion module).
Programming a function key
Programming of the function keys is effected during configuration of the system telephone with the PC.
You can program the five function keys on two levels with different functions.
System telephony
56
