Field Description
Clock Rate Define whether the clock rate should be negotiated.
Possible values:
• 5=: The clock rate is predefined.
• 0, (default value): The clock rate is negotiated de-
pending on the line quality.
Note that a fixed value must be set to use the IMA mode (see
: () on at least one side (CO or CPE).
Wire Mode Define the number and combination of wires (depending on the
device type) used for the SHDSL connection.
Possible values:
• : 2 wires are used with m-pair bonding for a clock rate
of 192 kbps to 5696 kbps.
• : Four wires are used with m-pair bonding for a clock
rate of 384 kbps to 11392 kbps. This option supports 4-wire
mode under G991.2 and Globespan Enhanced Mode.
• &: Four wires are used for m-pair bonding
with a clock rate of 384 kbps to 11392 kbps. This option sup-
ports 4-wire mode under G991.2 but not Globespan En-
hanced Mode.
• (0: 4 wires are used with IMA for a clock rate of
384 kbps to 11392 kbps.
• : 6 wires are used with m-pair bonding for a clock rate
of 576 kbps to 17088 kbps.
• (0: 6 wires are used with IMA for a clock rate of
576 kbps to 17088 kbps.
• : 8 wires are used with m-pair bonding for a clock rate
of 768 kbps to 22784 kbps.
• (0: 8 wires are used with IMA for a clock rate of
768 kbps to 22784 kbps.
Additional Wire Pairs Only for Wire Mode = , &,
(0, , (0.
For Wire Mode = , & or
(0 the second pair of wires is defined here.
11 Physical Interfaces Funkwerk Enterprise Communications GmbH
144 bintec Rxxx2/RTxxx2
