Field Description

URL

Only for Source Location = @++ & or +5+ &

Enter the URL of the update server from which the system soft-

ware file is loaded or on which the configuration file is saved.

Funkwerk Enterprise Communications GmbH

13 Wireless LAN Controller

bintec Rxxx2/RTxxx2 183
