Field Description
The default value is .
RTT Mode (Realtime
Traffic Mode)
Active or deactivate the real time transmission of the data.
The function is enabled with #/.
The function is disabled by default.
RTT mode should be activated for QoS classes in which real
time data has priority. This mode improves latency when for-
warding real time datagrams.
It is possible to configure multiple queues when RTT mode is
enabled. Queues with enabled RTT mode must always have a
higher priority than queues with disabled RTT mode.
Traffic Shaping Activate or deactivate data rate (=Traffic Shaping) limiting in the
send direction.
The data rate limit applies to the selected queue. (This is not the
limit that can be defined on the interface.)
The function is enabled with #/.
The function is disabled by default.
Maximum Upload
Speed
Only for Traffic Shaping enabled.
Enter a maximum data rate for the queue in kbits.
Possible values are to .
The default value is .
Overbooking allowed Only for Traffic Shaping enabled.
Enable or disable the function. The function controls the band-
width limit.
If Overbooking allowed is activated, the bandwidth limit set for
this queue can be exceeded, as long as free bandwidth exists
on the interface.
If Overbooking allowed is deactivated, the queue can never
occupy bandwidth beyond the bandwidth limit that has been set.
