Field Description
tification number of the virtual channel. A virtual channel is the
logical connection for the transport of ATM cells between two or
more points. Note your provider's instructions.
Possible values are ' to '.
The default value is 32.
Encapsulation Only for Provider = !! 3&! !!
Select the encapsulation to be used. Note your provider's in-
structions.
Possible values (in accordance with RFC 2684):
• 224 >$ 54-(Default value for Ethernet over ATM
: Is only displayed for Type = 0+(.
Bridged Ethernet with LLC/SNAP encapsulation without
Frame Check Sequence (checksums).
• 224 >$ 54- : only displayed for Type =
0+(.
Bridged Ethernet with LLC/SNAP encapsulation with Frame
Check Sequence (checksums).
• * -? (default value for Routed Protocols over ATM): Is
only displayed for Type = ; %/& 0+(.
Encapsulation with LLC/SNAP header, suitable for IP routing.
• 224 : only displayed for Type = 0+(.
Encapsulation with LLC header.
• 84 (/,/=$ (standard value for PPP over ATM):
Bridged Ethernet without additional encapsulation (Null En-
capsulation) with Frame Check Sequence (checksums).
Fields in menu Ethernet over ATM Settings (appears only for Type = Ethernet over
ATM)
Field Description
Default Ethernet for
PPPoE Interfaces
Only for Type = 0+(
Select whether this Ethernet-over-ATM interface is to be used
for all PPPoE connections
17 WAN Funkwerk Enterprise Communications GmbH
296 bintec Rxxx2/RTxxx2
