Field Description
• *&: Netmask for Remote IP Address
• (%: The lower the value, the higher the priority of the
route (possible values ). The default value is .
The menu Advanced Settings consists of the following fields:
Fields in the Advanced IPSec Options menu
Field Description
Phase-1 Profile Select a profile for Phase 1. Besides user-defined profiles, pre-
defined profiles are available.
Possible values:
• * & / ,/": Uses the profile marked
as standard in Phase-1 Profiles
• K-9 (/,,&/: Uses a special profile which con-
tains the proposals for Phase 1 3DES/MD5, AES/MD5 and
Blowfish/MD5 regardless of the proposal selection in menu
Phase-1 Profiles.
• A/B: Uses a profile configured in menu Phase-1
Profiles for Phase 1.
Phase-2 Profile Select a profile for Phase 2. Besides user-defined profiles, pre-
defined profiles are available.
Possible values:
• * & / ,/": Uses the profile marked
as standard in Phase-2 Profiles
• (/!,&/: Uses a special profile which contains the
proposals for Phase 2 3DES/MD5, AES-128/MD5 and Blow-
fish/MD5 regardless of the proposal selection in menu Phase-
2 Profiles.
• A/B: Uses a profile configured in menu Phase-2
Profiles for Phase 2.
XAUTH Profile Select a profile created in VPN->IPSec->XAUTH Profiles if you
wish to use this IPSec peer XAuth for authentication.
If XAuth is used together with IKE Config Mode, the transac-
tions for XAuth are carried out before the transactions for IKE
Config Mode.
