Field Description
identification of a particular table entry is derived from the com-
bination of Index Variable (usually an index variable which is
flagged with *) and Index Value.
Use Index Variables to create more entries with Add.
Trigger Status
Only if Command Type = (>7-*(
Select what status the event must have in order to modify the
MIB variable as defined.
Possible values:
• 0% (default value): The value of the MIB variable is mod-
ified if the initiator is active.
• %: The value of the MIB variable is modified if the ini-
tiator is inactive.
• >: The value of the MIB variable is differentially modified if
the initiator status changes.
MIB Variables
Only if Command Type = (>7-*(
Select the MIB variable whose value is to be configured as de-
pendent upon initiator status.
If the initiator is active (Trigger Status 0% ), the MIB vari-
able is described with the value entered in Active Value.
If the initiator is inactive (Trigger Status % ), the MIB
variable is described with the value entered in Inactive
Variable.
If the MIB variable is to be modified, depending on whether the
initiator is active or inactive (Trigger Status > ), it is de-
scribed with an active initiator with the value entered in Active
Value and with an inactive initiator with the value in Inactive
Variable.
Use Add to create more entries.
Interface
Only if Command Type = % -&
Select the interface whose status should be changed.
Set interface status
Only if Command Type = % -&
21 Local Services Funkwerk Enterprise Communications GmbH
450 bintec Rxxx2/RTxxx2
