8.3.1.3 Funkwerk Configuration Interface menus
The configuration options of your device are contained in the sub-menus, which are dis-
played in the navigation bar in the left-hand part of the window.
Note
Please note that not all devices have the full range of functions. Check the software of
your device on the corresponding product page under www.funkwerk-ec.com.
The Funkwerk Configuration Interface contains the following menus:
Assistants
Menu Function
First steps
In this menu you can make the basic settings that are required
to add your gateway to your local network (LAN).
Internet Access
The wizard guides you through the individual configuration
steps to connect your local network (LAN) to the internet.
VPN
In this menu you are guided through all of the settings that are
required to set up your LAN-LAN connection as a virtual private
network.
SWYX
In this menu, you can configure the settings required to connect
your device to the SWYX SIP server. In this case, your device
acts as a SIP client.
VoIP PBX in LAN The assistant is required, e.g. for specific PBX in the LAN, such
as Hybird in order to guarantee SIP compatibility. To do this,
external communication is carried out over a single IP address
and NAT is realised as full-cone NAT.
System Management
Menu Function
Status In this menu, general information on your device is displayed at
a glance.
This information includes serial number, software version, cur-
rent memory and processor use, status of the physical inter-
faces and the last 10 system messages.
Global Settings In this menu, you enter the basic system settings of your device,
Funkwerk Enterprise Communications GmbH
8 Access and configuration
bintec Rxxx2/RTxxx2 67
