52
NUMBER DESCRIPTION
1 SYSTEM INTERFACE PANEL “ICON”
2 CONNECTION CABLE FOR “ICON” INTERFACE PANEL
3 CONNECTION CABLE FROM POWER SUPPLY CONNECTOR TO BATTERY
(OPTIONAL), IN THE CASE THE SYSTEM IS NOT POWERED THROUGH THE
CONNECTOR ISO 12369
4 PROXIMITY SENSOR FOR SPEED DETECTION ON PHONIC WHEEL
NOTE: SPEED CAN ALSO BE DETECTED THROUGH:
• GPS DEVICE;
• SIGNAL ON ISO 11786 CONNECTOR
5 MAIN CABLE LOOM
6 SENSORS AND ACTUATORS DRIVING MODULE
7 ACTUATORS
8 WEIGHING MODULE WITH LOAD CELL (OPTIONAL)
