Use e Maintenance ENGLISH
3.1 TECHNICAL DATA
Model Hopper Transport Load Working Maximum Mass when
capacity width height width Load empty
(l) A (cm) B (cm) (m) * (kg) (kg)
PRIMO E213 1270 253 109 12 – 36 3200 439 – 549**
PRIMO E218 1805 253 124 12 – 36 3200 471 – 581**
PRIMO E224 2340 253 139 12 – 36 3200 503 – 613**
PRIMO E229 2875 253 154 12 – 36 3200 535 – 645**
PRIMO E314 1350 285 109 12 – 36 3200 448 – 578**
PRIMO E320 1970 285 124 12 – 36 3200 482 – 612**
PRIMO E326 2590 285 139 12 – 36 3200 516 – 646**
PRIMO E332 3210 285 154 12 – 36 3200 570 – 700**
Linkage category: 2 and 3N
Required tractor power: 120 HP and higher
Distance of the barycentre from the lower linkage points cat. 2 and 3N: S2 = 0.710m
NOISE LEVEL Noise measurements when empty, (UNI EN ISO4254-1:2010)
Sound pressure level: LpAm dB (A)...82.2
Sound power level: LwA dB (A) ........85
* Working width depends on how the spreading discs are configured.
** Maximum weight allowed with accessories applied.
The technical data and the models provided must be considered as non binding.
We reserve the right to change them without notice.
Table 3.1: Technical specifications
Figure 3.1: Dimensions
Cod. F07011577 EN - 17
