Launcher
Assemble the launcher
NOTE: If the launch cable is blocked while the elastics are not tightened, push the
release handles upwards to unblock them. Never do this when the elastics are tightened,
you will damage the elastics.
6 Put the launch dock on the end of the launch slide and slide it over the launch hook at the
beginning of the launch slide.
C
AUTION: Make sure the launch dock clicks into position.
