Chapter 7: Repair Procedures
Canopy Removal for Service
Service Manual 7-15
e. Check for and remove any sharp edges at each of the two corner cuts:
f. Reinstall the soffit using the six arrow clips.
g. Reinstall north seal.
20. Make sure that all seals can be easily removed:
a. Lift and unsnap the corner covers.
b. Slide the long side seals away from the display and
off the guide rails.
FIGURE 7-19. Untrimmed and Trimmed Soffit
After
Before
