GE Giraffe OmniBed Carestation CS1 - 1.13 Side View

Chapter 1: Functional Description
Side View
Service Manual 1-11
1.13 Side View
Feature
Number
Description
1 Mounting rail
2 Portholes
3 Canopy raise/lower arrows (switches)
4X-ray Tray
5 Pleural drainage hanger
6 Storage drawer
7 Bed Raise/Lower pedal
8 Elevating column
9 Wheel brake
10 Raise canopy pedal
2
3
7
5
1
6
8
10
9
Humidifier-end of
the device
Control Panel-
end of the device
4
