GE Giraffe OmniBed Carestation CS1 Service Manual

Chapter 8: Illustrated Parts
Humidifier Transformer and RS-232
Service Manual 8-11
8.5.2 Control Board Harness Connections
8.6 Humidifier Transformer and RS-232
1. Power supply*.........................................................................................2080961-001
2. M3 Kepsnuts ............................................................................................M1074118
3. Nylok Nut M4 ........................................................................................6600-0714-402
4. EXT Star washer, M4..........................................................................6600-0713-433
5. Washer, M4............................................................................................6600-0712-403
6. Humidifier isolation transformer 115/230V...........................2077510-001
Humidifier isolation transformer 100V.....................................2077537-001
7. Spacer, M3 x 18....................................................................................6600-1192-400
8. Screw, M6 skt. hd. ...............................................................................6600-0707-420
9. Lock washer, M6 int. tooth .............................................................6600-0713-434
10. Mounting bracket ...............................................................................6600-1587-500
11. Washer. M4 ............................................................................................0402-1133-300
12. Lock washer, M3 ext. tooth ............................................................6600-0713-442
13. Nylon lock nut, M3..............................................................................6600-0714-401
14. Wire harness. ISO transformer .....................................................6600-1526-700
15. Cable twist lock....................................................................................6600-1197-600
16. RS-232 chassis.....................................................................................2075202-001
17. Harness, RS-232..................................................................................2074735-001
18. Svc Kit RS-232 ......................................................................................2081096-001
19. Jack Screw, machine, 4-40X.375,
Hexagonal Socket, Stainless steel with Nylon Patch.........2077118-001
20. Clip RS-232.............................................................................................2086824-001
21. Isolation Shield RS-232.....................................................................2083113-001
22. Screw thread forming 30 x 10 ......................................................2066775-001
23. Washer FL M3.......................................................................................6600-0712-402
*The fuses on the power supply cannot be replaced. If the fuses are open there will be component damage that
necessitates replacing the entire power supply.
Name Part Number Connector
Environmental Sensor Panel Harness 6600-1513-700 J1
PAT Probe 2 Harness 6600-0716-702 J4
PAT Probe 1 Harness 6600-0716-701 J2
Heat Sink Probe Harness 6600-0742-700 J3
Scale Harness 6600-0728-700 J7
Display Data Harness 6600-0703-700 J8
DC Power Harness* 6600-0701-700 J5
Relay Data Harness* 6600-0704-700 J9
*These harnesses come from the Relay Board.
