Chapter 3: Calibration and Maintenance
Service Maintenance Schedule
3-2 Service Manual
FIGURE 3-1. Control Board Test Points
J1
J4
J2
Calibration
jumper
Test Point 1
Dipswitch
Test Point 2
12345678
