GE Giraffe OmniBed Carestation CS1 - FIGURE 8-35. Dovetail Mount DIN Rail (6600-0659-803)

Chapter 8: Illustrated Parts
Options
Service Manual 8-59
1. Mounting bracket housing........................................... 6600-1541-500
2. Mounting bracket lock.................................................... 6600-1542-500
3. Screw, M4 x12..................................................................... 6600-0853-400
4. DIN rail ................................................................................... 6600-1540-503
(Order item 7 at the same time.)
5. Spacer ................................................................................... 6600-1538-500
6. Screw, M8 x 35 Skt Hd..................................................... 6600-0852-400
7. Weight limit label................................................................. M1160984
FIGURE 8-35. Dovetail Mount DIN Rail (6600-0659-803)
4
5
6
2
3
1
7
