Chapter 4: Understanding the Service Interface
4.1 Powering the Device
This section describes how to turn the device On and Off.
Isolation of the device from the supply mains can only be achieved by turning off the device using the mains
power switch on the rear of the device. The standby switch on the probe panel will not isolate the device
from the supply mains.
To turn the device On:
1. Plug the power cord into a grounded outlet or, where available, a hospital grade outlet.
Note: If the device has not been unplugged, verify that the device is plugged in and that the Mains power
switch is turned On.
2. Turn on power at the Mains power switch on the back of the device.
3. Turn on the power at the Standby switch on the probe panel.
When power is applied, the indicator light and Power Fail Indicator Light briefly turn on an then off. A
series of informational screens are displayed.
The device is ready for use when the Home screen appears.
To turn the device Off:
1. Turn off the power at the Standby switch.
2. If the device will be moved, turn off the Mains power switch at the back of the device, unplug the device,
and wrap the cord for safe transport.
3. If the device will not be moved, no other action is needed for powering on or off.
4.2 Accessing Service Mode
By default, the device starts up in user mode. A series of user-hidden actions allows service personnel to
access Service Mode.
To access service mode:
1. In user mode, touch Setup on the Home screen.
The Setup screen appears.
2. Touch the data Baby Name field Enter here.
The keyboard appears.
FIGURE 4-1. User Setup Screen
To Next Page
