GE Giraffe OmniBed Carestation CS1 Service Manual

Chapter 8: Illustrated Parts
Electrical Enclosure
8-6 Service Manual
36. Board retaining bracket.................................................6600-1822-500
37. M3 Nut for bracket ...........................................................6600-0711-403
38. Screw, M4 x 6 ......................................................................…6600-0706-407
39. Lock washer M4.................................................................6600-0713-403
40. Label Ground Mains.........................................................……0205-4735-300
41. Locknut M4 .......................................................................... 6600-0714-402
42. Nut M4....................................................................................6600-0711-407
43. Lock Washer 5/16”...........................................................6600-0608-400
44. Grommet...............................................................................0211-1472-300
45. Grommet w/Adhesive ....................................................M1110049
6600-1349-500 and Door Hardware Screw Sems M4 x 10 6600-0908-401 (Not shown)
46. Enclosure Door...................................................................6600-1349-500
47. Harness Ground Equalization Post...........................6600-0870-700
48. SSR Filter Cap...................................................................... 2078678-001
49. Harness Warmer Heater/SSR .....................................6600-0882-700
50. Harness Power Supply AC Input ................................ 2093759-001 (Not shown)
Harness Power Supply AC Input Ground ............... 2075836-001 (Not shown)
51. Harness AC Mains connection....................................6600-0731-700
(Not shown; connects to the Filter harness, Power Switch, Line Filter, and Power Outlets)
52. Harness INC Heater, .......................................................6600-0709-700
53. Screw M4 x 6 Skthd..........................................................6600-0707-407
54. M3 SPLK washer................................................................ 6600-0713-402
55. M3 Fl Washer ......................................................................6600-0712-402
56. Screw M4 x 10 ....................................................................6600-0706-409
Also refer to power cords in section “8.18 Options PNs”.
