GE Giraffe OmniBed Carestation CS1 Service Manual

Chapter 8: Illustrated Parts
Bed and Side Panels
Service Manual 8-15
1. Giraffe OmniBed side wall (Acrylic) with
porthole cutouts................................................................ 6600-1107-500
Giraffe OmniBed side wall (Polycarbonate) with
porthole cutouts** ........................................................... 6600-1685-500
Giraffe OmniBed East/West Door Kit (Acrylic)
(Includes side wall, portholes, hinges, inner wall,
door latches) ....................................................................... 6600-0267-850
Giraffe OmniBed East/West Door Kit (Polycarbonate)
(Includes side wall, portholes, hinges, door latches;
does not include inner wall)**.....................................6600-0134-850
2. Giraffe OmniBed inner wall..........................................6600-1201-500
3. Porthole seal ....................................................................... 6600-1249-500
4. Wall hinge snap................................................................. 6600-1436-500
5. Side wall hinge................................................................... 6600-1149-500
6. Side wall hinge mask label...........................................6600-2321-100
7. Giraffe OmniBed side wall inside latch cover...... 6600-1406-500
8. Porthole hinge bottom ................................................... 6600-1239-500
9. Side wall latch .................................................................... 6600-1403-500
10. Screw, M2.9 x 9.5............................................................... 6600-0709-409
11. Side wall latch spring...................................................... 6600-1405-500
12. Side wall latch cover........................................................ 6600-1404-500
13. Wall hinge snap post....................................................... 6600-1429-500
14. Porthole hinge right (East) spring*............................ 6600-1026-400
15. Porthole middle hinge..................................................... 6600-1240-500
16. Hinge pin............................................................................... 6600-1041-400
17. Porthole hinge left (West) spring* .............................6600-1040-400
18. Flat washer .......................................................................... 6600-0712-403
19. Split ring lock washer, M4.............................................. 6600-0713-403
20. Screw, M4 x 16.................................................................... 6600-0706-411
21. Porthole hinge cover ....................................................... 6600-1242-500
22. Porthole door...................................................................... 6600-1238-500
23. Porthole latch cover* ...................................................... 6600-1246-500
24. Porthole latch spring....................................................... 6600-1245-500
25. O-ring...................................................................................... 6600-1049-400
26. Porthole latch base*........................................................ 6600-1244-500
27. Plastic washer ....................................................................6600-1050-400
28. Screw, M2.9.......................................................................... 6600-0709-407
29. Porthole latch spacer...................................................... 6600-1257-500
30. Screw, M4 x 12.................................................................... 6600-0706-410
31. Porthole Latch Assembly (Includes 23-28)............ 6600-0738-700
Parts Not Shown
Oscillator (High Freq. Vent) port cover .................... 6600-0838-800
** Polycarbonate side walls are suitable for Giraffe OmniBed units that use high humidity settings for prolonged periods
of time. (Acrylic side walls will warp in units that use high humidity settings for prolonged periods of time.)
* Use Vac Kote (6700-0092-200) sparingly on the porthole door springs (items 14 and 17) and on the surfaces where the
door latch pieces (items 23 and 26) slide together.
