Chapter 8: Illustrated Parts
Radiant Heater and Canopy
Service Manual 8-23
Kits for canopy seals:
Seal Replacement Kit (contains the following parts)M1208284
1. West Canopy Seal, quantity 1
2. South Canopy Seal, quantity 1
3. East Canopy Seal, quantity 1
4. North Canopy Seal, quantity 1
Corner Cover Replacement Kit (contains the following parts)M1208283
5. Corner Cover SE, quantity 1
6. Corner Cover SW, quantity 1
7. Corner Cover Receiver, quantity 2
8. M4 x 16 Flathead Phillips Screw with Pre-applied Nylon Patch, quantity 2
Hardware Replacement Kit (contains the following parts)M1208285
9. . M4 x 16 Flathead Phillips Screw with Pre-applied Nylon Patch, quantity 2
10. .West Canopy Rail, quantity 1
11. .South Canopy Rail, quantity 1
12. East Canopy Rail, quantity 1
13. North Canopy Spacer, quantity 1
14. Rail Spacer, quantity 2 (thicker than spacer washer)
15. Flange Corner NW, quantity 1
16. Flange Corner NE, quantity 1
17. Canopy Corner Pin, quantity 4
18. Canopy Corner Pin Gasket, quantity 4
19. Door Support, quantity 2
20. Door Support Gasket, quantity 2
21. Spacer Washer, quantity 20
22. Smooth Nut, quantity 20
23. M4 x 20 Buttonhead Socket Cap Screw, quantity 2
24. M4 x 16 Buttonhead Socket Cap Screw, quantity 10
25. M4 x 30 Socket Set Screw Cup Point Stainless Steel, quantity 6
26. .M4 x 4.1 id 0.9 Thick Splitlock Washer, quantity 14
M4 Hex Nut Stainless Steel, quantity 6 (not shown)
M4 x 4.3 id 0.5 Star Washer External, quantity 6 (not shown)
M4 x 12 Buttonhead Stainless Steel Screw, quantity 2 (not shown)
M4 x 4.3 id 0.8 Flat Washer, quantity 4 (not shown)
M1224510 Small Hardware, Canopy Seal Omnibed
DOOR SUPPORT GH
FLANGE CORNER CAN SE NW GH
FLANGE CORNER CAN SW NE GH
M4 X 4.3ID 0.5 STAR WSHR EXT
M4 X 4.3ID 0.8 FL WSHR ROHS
M4 X 12 BTNHD SCR SST
M4 X 16 BTNHD SCR SST
M4 X 20.0 BTNHD SCR SST
M4X0.7X16 FLHD PH W/NYLO K
M4X4.1ID X 0.9 THK SPLK WSHR
NUT, M4 X 0.7 HEX NUT SST
PART, CANOPY CORNER PIN GASKET, Machined
PART, DOOR SUPPORT GASKET GH, Machined
