GE Giraffe OmniBed Carestation CS1 Service Manual

Chapter 8: Illustrated Parts
Radiant Heater and Canopy
Service Manual 8-25
1. Foil door, right (East)* ...................................................... 6600-1454-500
2. Heater door, right (East)*............................................... 6600-1309-500
3. Foil door, left (west)* ........................................................ 6600-1453-500
4. Heater door, left (west)* ................................................. 6600-1310-500
5. Lower pivot bearing......................................................... 6600-1059-400
6. Elastic lock nut, M3.......................................................... 6600-0714-401
7. Spherical bearing block................................................. 6600-1058-400
8. Top bearing spacer.......................................................... 6600-1702-500
9. Interface bracket .............................................................. 6600-1215-500
10. Shoulder screw, socket head....................................... 6600-1113-400
11. Washer................................................................................... 6600-1163-400
12. Top seal.................................................................................. 6600-1709-500
13. Bottom seal.......................................................................... 6600-1710-500
14. Gasket .................................................................................... 6600-1396-500
15. Door switch.......................................................................... 6600-1154-600
16. Locking nut, 2 -56............................................................. 6600-1165-400
17. Cam spacer.......................................................................... 6600-0925-400
18. Inner cam (white) with notch....................................... 6600-1893-500
19. Outer cam (white) with notch...................................... 6600-1892-500
20. Washer, .175 ID x .875 OD............................................. 0402-1133-300
21. Split ring washer................................................................6600-0713-403
22. Screw, M4 x 10 button head ........................................ 6600-0706-409
23. KEEPER PLATE EAST GH, Sheet metal...................... 6600-1644-502
24. KEEPER PLATE WEST GH (NOT SHOWN).................. 6600-1644-501
25. Warmer Heater Door Sensor Harness.................... 6600-0752-700
* Always order heater door and foil to install at the same time.
