Chapter 8: Illustrated Parts
Uprights and Lift Rail Components
Service Manual 8-37
1. Upper buoyancy spring*............................................... 6600-1464-500
2. Spool....................................................................................... 6600-1317-500
3. Plastic washer .................................................................... 6600-1708-500
4. Lock nut, M3........................................................................ 6600-0714-401
5. Lower buoyancy spring*............................................... 6600-1465-500
6. Spacer.................................................................................... 6600-1491-500
7. Belt switch assembly guide ......................................... 6600-1769-500
Parts Not Shown
Micro-switch (part of switch harness).............................. Refer to wiring diag.
Switch hardware
Screw, M2 x 16 fillister head.......................................6600-0710-408
Split ring lock washer, M2 ............................................. 6600-0713-401
NutM2..................................................................................... 6600-0711-401
Nut M3 ................................................................................... 6600-0711-403
Screw M3 x 16 Flat head............................................... 6600-0708-405
Grooved Pin......................................................................... 6600-1185-400
*Replace all the buoyancy springs at one time.
