Chapter 8: Illustrated Parts
Uprights and Lift Rail Components
Service Manual 8-39
1. Washer ..................................................................................6600-1088-400
2. Outer roller........................................................................... 6600-1318-500
3. Short bearing...................................................................... 6600-1086-400
4. Lock washer, internal tooth .........................................6600-0713-434
5. Screw, M6 x 16 button head........................................ 6600-0706-428
6. Inner roller............................................................................ 6600-1750-500
7. Stepped bushing............................................................... 6600-1749-500
8. Screw, M6 x 20 button head........................................ 6600-0706-429
9. Screw, M5 x 20 socket head ........................................ 6600-0707-480
10. Standoff................................................................................. 6600-1740-500
11. Rail brake pad .................................................................... 6600-1161-400
12. Roller bracket post assembly...................................... 6600-0809-700
13. Roller tensioning spring (left/west) ........................... 6600-1162-400
