Chapter 8: Illustrated Parts
Servo Control Oxygen
8-48 Service Manual
1. Screw, M4x12L Skt Hd..................................................... 6600-0707-410
2. Split ring washer, M4 ....................................................... 6600-0713-403
3. Valve housing top cover................................................6600-1838-500
4. Valve housing wire harness......................................... 6600-1069-700
5. Adapter 1/8NPTFx1/8NPTM......................................... 6700-0616-800
6. Elbow fitting 10 OD x1/8NPT.......................................6600-0873-400
7. Screw, M4 Skt Hd...............................................................6600-1051-400
8. Flat washer, M5..................................................................6600-0712-409
9. Damper manifold mount .............................................. 6600-1248-400
10. Valve housing...................................................................... 6600-1836-500
11. Valve housing bottom cover........................................6600-1837-500
12. Jam nut, M14...................................................................... 6600-0711-450
13. Label Max kPa6..................................................................600-2448-101
Label Max PSI......................................................................6600-2448-102
14. Lock washer, M14 Int tooth..........................................6600-0713-438
15. Push-in fitting, 90° Elbow.............................................. 6600-0865-400
16. Supply valve.........................................................................6600-0602-700
17. Manifold.................................................................................6600-1839-500
Plug..........................................................................................0413-3510-335
Gasket ....................................................................................6600-1950-500
18. Regulator assembly.........................................................6600-0254-850
In-line screen fitting ........................................................ 6600-1249-400
19. O2 adapter, Air Liquide ................................................... M1230430
20. O2 adapter, DIN .................................................................6700-0050-700
21. O2 adapter, NIST................................................................6600-0100-400
22. O2 adapter, DISS................................................................6700-0522-800
23. O2 adapter SIS ................................................................... M1139871
24. Washer, M4 ..........................................................................6600-0712-403
Parts Not Shown
Oxygen inlet label (green).......................................................6600-2611-101
Valve housing assembly (includes all parts
above except items 11, 13
and mounting hardware)..............................................6600-1507-700
6 mm Tubing (order by inch)........................................ 6600-0866-400
From regulator to manifold, 3.9”
Tubing/sleeve assembly................................................6600-0262-850
10 mm tube from valve housing to expansion chamber, 27”
