GE PANDA Service Manual

Chapter 6: Illustrated Parts
Electronics Enclosure
Service Manual 6-5
12. Wire harness warmer observation
light switch...................................................6600-1588-700
†
13. Observation light knob............................... 2076390-001
†
14. Standby switch.............................................6600-1356-600
15. Touch panel.............................................................M1118319
(For units with SpO
2
, order logo label indicated in
section 6.11.)
16. Electronics enclosure..........................................M1109562
17. Split ring retainer.........................................6600-1296-400
18. Screw, M4 X 8 captive ...............................6600-0868-401
19. Alarm light board ............................................2074881-001
20. Nut, M4 X 0.7.................................................6600-0711-407
21. Split ring washer M4 x 4.1, 0.9 ..............6600-0713-403
22. Potentiometer mount........................................M1129877†
23. Washer, plastic.......................................................M1129879
* Battery must have heat shrink around it to avoid damage.
†
If the wire harness warmer observation light switch has a
metal shaft, you will need to order all four items: 12, 13, 22,
and 23.
TABLE 6-1. LED Illustrated Parts Matrix for the Electronics Enclosure
Failed Part Required Replacement
Part Number
(PCA/Display) Revision Description
Service Kit
Part Number Description
1087687 Any PCA Warmer Control 2090844-001 IEC Alarms Upgrade Kit - With
Control Board
2065760-001 A - H Control Board RoHS, Warmer 2090844-001 IEC Alarms Upgrade Kit - With
Control Board
2065760-001 J - L Control Board RoHS, Warmer 2092027-001 Warmer Control Board Kit: IEC
Alarms Software
2096185-001 Any Control Board RoHS, Warmer,
LED Display
2096186-001 Warmer Control Board Kit: LED
Display
T-51750GD065J-FW-AJN LCD Display 2096917-001 ASSY-LAU, Service Kit Display,
Kyocera 6.50 LED Upgrade
T-51750GD065J-LW-AYN Display Kyocera 6.50,
LED Backlit
2096187-001 ASSY-LAU, Service Kit Display,
OPITREX 6.50 LED, Spare Part

GE PANDA Specifications

General

Type	Infant Warmer
Manufacturer	GE Healthcare
Control Modes	Manual, Servo
Integrated Scale	Yes
SpO2 Monitoring	Optional
Bed Tilt	Yes
Heater Type	Ceramic
Alarms	Power Failure
Power Requirements	100-240 VAC, 50/60 Hz
Model	PANDA
Resuscitation Options	Optional
Skin Temperature Probe Accuracy	±0.3°C
