Chapter 6: Illustrated Parts
Base Assembly (Bedded Models Only)
Service Manual 6-11
Note: It is important to select the correct version of elevating column as they are not forward or backward
compatible. Read thoroughly and understand the “Elevating Column Special Instructions” before
selecting a part number.
TABLE 6-2. Elevating Column
Item # Description Variant 1 (Part Number
IS NOT Displayed)
Variant 2 (Part Number
IS Displayed)
2 Screw, M10x45, btn hd M1074119
2 Screw, M8x40, btn hd M1161801
3 Split ring washer, M10 6600-0713-407
3Split ring washer, M8 6600-0713-406
5 Insulating sheet M1106932 M1161569
6 Base shroud 6600-2048-500 M1152760
7 Elevating column, 115 VAC 6600-2049-501 M1137168
7 Elevating column, 230 VAC 6600-2049-502 M1137170
7 Elevating column, 100 VAC
M1137172
7 Elevating column, manually adjusted 6600-2049-504
(pin design)
M1137173
(crank handle design)
8 Base plate 6600-2094-500 M1154653
22 Main bracket 6600-2050-500 M1156495
