Ch 0 … Ch 3: TimeStamp at
edge 1-0
disabled (0) /
enabled (1)
disabled
Product
Part No.
Parameter
Optional values
Default value
Digital Output, 4
Points, Positive Logic
24VDC, 0.5A, 2, 3, or 4
Wire
Digital Output, 4
Points, Positive Logic
24VDC, 2.0A, 2, 3, or 4
Wire
EP-2214
EP-2614
Ch 0 … Ch 3: Substitute value
Off (0) / On (1)
Off
Product
Part No.
Parameter
Optional values
Default value
Digital Output, 4
Points, Positive/
Negative Logic
24VDC, 2.0A, 2, 3, or 4
Wire
EP-2634
Ch 0 … Ch 3: Substitute value
OP-Mode
Sinking (0) /
Sourcing (1)
Sourcing
Ch 0 … Ch 3: Substitute value
Off (0) / On (1)
Off
Product
Part No.
Parameter
Optional values
Default value
Digital Output, 8
Points, Positive Logic,
24VDC, 0.5A, 2 Wire
EP-2218
Ch 0 … Ch 7: Substitute value
Off (0) / On (1)
Off
Product
Part No.
Parameter
Optional values
Default value
Digital Output, 4
Points, Positive Logic,
230 VAC, 0.5A
Digital Relay Output,
4 Points, Positive
Logic, 24 - 220
VDC/VAC, 6A, 2 Wire
EP-2814
EP-2714
Ch 0 … Ch 3: Substitute value
Off (0) / On (1)
Off
Product
Part No.
Parameter
Optional values
Default value
1 Channel High
Speed Counter, AB
100 kHz 1 DO 24VDC,
0.5A
EP-5111
Diagnostic alarm
disabled (0) /
enabled (1)
disabled
Ch 0: Filter time signal A
0,01 ms [100 kHz] (0)
/ 0,017 ms [50 kHz]
(1) / 0,033 ms [30
kHz] (2) / 0,1 ms [10
kHz] (3) / 0,2 ms [5
kHz] (4) /0,5 ms [2
kHz] (5) /1 ms [1 kHz]
(6)
0,01 ms
Ch 0: Filter time signal B
0,01 ms [100 kHz] (0)
/ 0,017 ms [50 kHz]
(1) / 0,033 ms [30
kHz] (2)/ 0,1 ms [10
kHz] (3) /0,2 ms [5
kHz] (4)/ 0,5 ms [2
kHz] (5) / 1 ms
[1 kHz] (6)
0,01 ms
Ch 0: Filter time latch
0,01 ms (0) / 0,017 ms
(1) / 0,033 ms (2) / 0,1
ms (3) / 0,2 ms (4) /
0,5 ms (5) / 1 ms (6)
0,01 ms
