GE RSTi-EP - Page 44

Chapter 3: Configuration
GFK-2958E RSTi-EP User Manual 40
Ch 0: Filter time gate
0,01 ms (0) / 0,017 ms
(1) / 0,033 ms (2) / 0,1
ms (3) / 0,2 ms (4) /
0,5 ms (5)/ 1 ms (6)
0,01 ms
Ch 0: Filter time reset
0,01 ms (0) / 0,017 ms
(1) / 0,033 ms (2) / 0,1
ms (3) / 0,2 ms (4) /
0,5 ms (5) / 1 ms (6)
0,01 ms
Ch 0: Process alarm HW gate
open
disabled (0) /
enabled (1)
disabled
Ch 0: Process alarm HW gate
closed
disabled (0) /
enabled (1)
disabled
Ch 0: Process alarm overflow
disabled (0) /enabled (1)
disabled
Ch 0: Process alarm underflow
disabled (0) /
enabled (1)
disabled
Ch 0: Process alarm comp.
value
disabled (0) /
enabled (1)
disabled
Ch 0: Process alarm end value
disabled (0) /
enabled (1)
disabled
Ch 0: Process alarm latch value
disabled (0) /
enabled (1)
disabled
Ch 0: Counting mode
count endless (0) /
once - forward (1) /
once - backwards (2)/
once - no main
direction (3) /
periodic - forward (4)/
periodic - backwards
(5) /periodic - no
main direction (6)
count endless
Ch 0: Condition for DO
disabled (0) / higher
equal comparison
value (1) /lower equal
comparison value (2)/
equal comparison
value (3)
disabled
Ch 0: Counter dir. signal B inv.
disabled (0) /
enabled (1)
disabled
Ch 0: Reset
disabled (0) / high
level (1) / rising edge
0-1 (2)/rising edge
once 0-1 (3)
disabled
Ch 0: Signal mode
Rotary transducer -
single (0) / Rotary
transducer -
double (1) / Rotary
transducer -
quadruple (2) /Pulse
and Direction (3) /
disabled (4)
disabled
Ch 0: HW gate
disabled (0) /
enabled (1)
disabled
