GE Vivid i

Measurement and Analysis
114 Vivid i User’s Manual
2378958-100 Rev. 02
Measure and Assign modality
In this measurement modality, the user performs a
measurement and assign a label.
Starting the Measure and Assign
modality
1. Press MEASURE on the control panel.
The Measurement Menu is displayed in the Parameters
window (see example Figure 6-3).
2. Select the Generic study if not already selected, and
trackball to the required measurement tool.
3. Press
SET on the trackball area to activate the
measurement tool.
The cursor is moved back to the scanning window, ready
for measurement.
Figure 6-3: The 2D Mode Measurement tools (Cardiac application)
CAUTION
Only assigned measurements will be saved.
1. Measurement tools
