Getting started
26 Vivid i User’s Manual
2378958-100 Rev. 02
Key illumination
The keys on the control panel are illuminated according to their
availability:
• Illumination in green: the key function is currently active.
• Illumination in yellow: the key function is available (but
not active) in the current state of the scanner.
• No illumination: The key is not available in the current
state of the scanner.
Power On/Off key
Navigation keys
Key Description
Turns the unit ON and OFF.
Sets the unit to Standby.
Key Description
Displays the Archiving opening page. Enables
the user to perform the following functions:
• Create a new patient record
• Edit the current patient’s information
• Browse the Patient List to search for patient
records
• End the current examination
For further information, refer to page 42.
Displays the Select Probe and Application dialog
box that enables the users to select the desired
probe and application preset for the current
examination. For information about selecting
probes, refer to page 46 and page 263.
