Scanning Modes
86 Vivid i User’s Manual
2378958-100 Rev. 02
Gain, Frequency,
Focus, Dynamic
Range and Com-
pression affect also
the 2D image.
3. Adjust horizontal sweep, Gain, Frequency, Focus, Dynamic
Range, Compression and Contour to optimize the display if
necessary.
4. Press
FREEZE to stop imaging.
Conventional Color M-Mode
1. While in Color Mode press cursor on the control panel.
2. Use the trackball to position the cursor over the required
area of the image.
3. Press
MM - the Color M-mode sweep will start to sweep.
4. Press
FREEZE to stop imaging.
OR
1. While in Color Mode press
M on the control panel. The
Color M-mode sweep will start to sweep.
2. Use the trackball to position the cursor over the required
area of the image.
3. Adjust horizontal sweep, Gain, Frequency, Focus, Dynamic
Range, Compression and Contour to optimize the display if
necessary.
4. Press
FREEZE to stop imaging.
Anatomical M-Mode
Anatomical M-Mode is only available for cardiac applications.
Anatomical
M-Mode can also
be used with previ-
ously acquired digi-
tally stored 2D
images.
1. Enter live M-mode.
2. Press the assignable
AMM soft key to enter Live
Anatomical M-mode. Continue to step 4 below.
OR
1. From the 2D Live, press
FREEZE.
2. Press
MM to access the Freeze Anatomical M-Mode.
The Trackball as-
signable Pos (Posi-
tion) is activated.
3. Use the trackball to position the cursor over the required
area of the image.
The Trackball as-
signable Angle is
activated.
4. Press TRACKBALL to allow free rotation of the solid
full-length cursor line throughout the 2D image.
5. Rotate the solid cursor line to the desired direction.
The Trackball as-
signable Pos is acti-
vated.
6. Press TRACKBALL twice and reposition the intersection
point to the desired position along the cursor line.
