■ Mechanical dimensions
All the below listed measurements are in mm.
VLT type A B C D a b ab/be Type
Bookstyle IP 20
5001 - 5003 200 - 240 V
5001 - 5005 380 - 500 V
395 90 260 384 70 100 A
5004 - 5006 200 - 240 V
5006 - 5011 380 - 500 V
395 130 260 384 70 100 A
Compact IP 00
5032 - 5052 200 - 240 V
5060 - 5100 380 - 500 V
800 370 355 780 270 225 B
5125 - 5250 380 - 500 V 1400 420 400 1380 350 225 B
5300 - 5500 380 - 500 V 1896 1099 494 1847 1065 400
1)
I
Compact IP 20
5001 - 5003 200 - 240 V
5001 - 5005 380 - 500 V
395 220 160 384 200 100 C
5004 - 5006 200 - 240 V
5006 - 5011 380 - 500 V
395 220 200 384 200 100 C
5008 200 - 240 V
5016 - 5022 380 - 500 V
560 242 260 540 200 200 D
5011 - 5016 200 - 240 V
5027 - 5032 380 - 500 V
700 242 260 680 200 200 D
5022 - 5027 200 - 240 V
5042 - 5062 380 - 500 V
800 308 296 780 270 200 D
5032 - 5052 200 - 240 V
5060 - 5100 380 - 500 V
954 370 335 780 270 225 E
5125 - 5250 380 - 500 V 1532 420 400 1380 350 225 E
Compact Nema 1 with terminals
5032 - 5052 200 - 240 V
5060 - 5100 380 - 500 V
1004 370 335 780 270 225 E
5125 - 5250 380 - 500 V 1582 420 400 1380 350 225 E
Compact Nema 1
5300 - 5500 380 - 500 V 2060 1200 600 - - 400
1)
H
Compact IP 54
5001 - 5003 200 - 240 V
5001 - 5005 380 - 500 V
460 282 195 85 260 258 100 F
5004 - 5006 200 - 240 V
5006 - 5011 380 - 500 V
530 282 195 85 330 258 100 F
5008 - 5011 200 - 240 V
5016 - 5027 380 - 500 V
810 355 280 70 560 330 200 F
5016 - 5027 200 - 240 V
5032 - 5062 380 - 500 V
940 400 280 70 690 375 200 F
5032 - 5052 200 - 240 V
5060 - 5100 380 - 500 V
937 495 421 - 830 374 225 G
5125 - 5250 380 - 500 V 1572 495 425 - 1465 445 225 G
5300 - 5500 380 - 500 V 2010 1200 600 - - - 400
1)
H
ab: Minimum space above enclosure
be: Minimum space below enclosure
1: Only above enclosure (ab) IP 00 when built in a Rittal cabinet.
