■ Electrical installation
The voltage on the frequency converter is
d
angerous when the unit is connected to
m
ains. Incorrect installation of the motor
o
r VLT frequency converter may lead to material
damage or serious injury or it may be fatal. Conse-
quently, the instructions in this manual as well as
national and local rules and safety regulations must
b
e complied with.T
o
uching the electrical parts may
be fatal, even after the mains supply has been dis-
connected. Wait at least 4 minutes if using VLT
5
001-5006 and at least 15 minutes if using VL
T
5008-5500.
NB!:
It is the user’s or certified electrician’s
responsibility to ensure correct earthing and
protection in accordance with applicable national and
local norms and standards.
All terminals for the control cables are located under
the protective cover of the VLT frequency converter.
The protective cover (see drawing) can be removed
by means of a pointed object - a screwdriver or simi-
lar.
Once the protective cover has been removed, the
actual EMC-correct installation can start. See draw-
ings in the section, EMC correct installation .
