GEA ARIETE - Operation and Display

VLT
®
5000 Series
■ Operation and Display
001
001 Language
(LANGUAGE)
Value:
✭English (ENGLISH)
[0]
German (DEUTSCH)
[1]
French (FRANCAIS)
[2]
Danish (DANSK)
[3]
Spanish (ESPAÑOL)
[4]
Italian (ITALIANO)
[5]
Function:
The choice in this parameter defines the language to
be used on the display.
Description of choice:
There is a choice of English [0], German [1], French
[2], Danish [3], Spanish [4] and Italian [5].
002
002 Local/remote control
(OPERATION SITE)
Value:
✭Remote control (REMOTE)
[0]
Local control (LOCAL)
[1]
Function:
There is a choice of two methods of controlling the
VLT frequency converter: Remote control [0] and Lo-
cal control [1].
Description of choice:
If Remote control [0] is selected, the VLT frequency
converter can be controlled via:
1. The control terminals or the serial communication
port.
2. The [START] key. However, this cannot overrule
Stop commands (also start-disable) entered via
the digital inputs or the serial communication port.
3. The [STOP], [JOG] and [RESET] keys, provided
that these are active (see parameters 014, 015
and 017).
If Local control [1] is selected, the VLT frequency
converter can be controlled via:
1. The [START] key. However, this cannot override
Stop commands on the digital terminals (if [2] or
[4] has been selected in parameter 013).
2. The [STOP], [JOG] and [RESET] keys, provided
that these are active (see parameters 014, 015
and 017).
3. The [FWD/REV] key, provided that this has been
activated in parameter 016 and that in parameter
013 a choice of [1] or [3] has been made.
4. Via parameter 003 the local reference can be
controlled by means of the "Arrow up" and "Arrow
down" keys.
5. An external control command that can be con-
nected to terminal 16, 17, 19, 27, 29, 32 or 33.
However, [2] or [4] must be selected in parameter
013.
See also section Shift between local and remote
control .
003
003 Local reference
(LOCAL REFERENCE)
Value:
Par 013 set for [1] or [2]:
0-f
MAX
✭ 000.000
Par 013 set for [3] or [4] and par. 203 = [0] set for:
Ref
MIN
- Ref
MAX
✭ 000.000
Par 013 set for [3] or [4] and par. 203 = [1] set for:
-Ref
MAX
- + Ref
MAX
✭ 000.000
Function:
This parameter allows manual setting of the desired
reference value (speed or reference for the selected
configuration, depending on the choice made in pa-
rameter 013).
The unit follows the configuration selected in param-
eter 100, provided Process control, closed loop [3]
or Torque control, open loop [4] has been selected.
Description of choice:
Local [1] must be selected in parameter 002 for this
parameter to be used.
The set value is saved in the case of a voltage drop-
out, see parameter 019.
In this parameter Data Change Mode is not exited
automatically (after time out).
Local reference cannot be set via the serial commu-
nication port.
Warning: Since the value set is remem-
bered after the power has been cut, the
motor may start without warning when the
power is reinstated; if parameter 019 is changed to
Auto restart, use saved ref. [0].
004
004 Active Setup (ACTIVE SETUP)
Value:
Factory Setup (FACTORY SETUP)
[0]
✭Setup 1 (SETUP 1)
[1]
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.51.A1.02 - VLT is a registered Danfoss trade mark
104
