H3YN
H3YN
7
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Timers
H3YN-2/-21 Front Mounting
H3YN-4/-41 Front Mounting
H3YN-4-Z/-41-Z
Mounting Height
PYF08A/PYF08A-N/PYF08A-E
(PYF14A/PYF14A-N/PYF14A-E
(see
note))
PY08 (PY14 (see note)) PY08QN (PY14QN (see note))
Note:
Models in parentheses are Sockets connecting to the H3YN-4/-4-Z.
Fourteen, 3 × 1.2 elliptic holes
28 max.
21.5 max
28 max.
21.5 max
H3YN
Series
H3YN
Series
H3YN
Series
PY08 (PY14)
PY08QN
(PY14QN)
PYF08A (PYF14A)
6.4
(63)
Eight, 3 x 1.2 elliptic holes
