Setup 2 (SETUP 2)
[2]
Setup 3 (SETUP 3)
[3]
Setup 4 (SETUP 4)
[4]
MultiSetup (MULTI SETUP)
[5]
Function:
The choice in this parameter defines the Setup num-
ber you want to control the functions of the VLT
frequency converter.
All parameters can be programmed in four individual
parameter Setups, Setup 1 - Setup 4. In addition,
there is a pre-programmed Setup, called Factory
Setup, that cannot be modified.
Description of choice:
Factory Setup [0] contains the data set at the works.
Can be used as a data source if the other Setups
are to be returned to a known state.
Parameters 005 and 006 allow copying from one
Setup to one or more of the other Setups.
Setups 1-4 [1]-[4] are four individual Setups that can
be selected as required.
Multi-Setup [5] is used if remote-mounting switching
between Setups is desired. Terminals 16/17/29/32/
33 as well as the serial communication port can be
used for switching between Setups.
005
005 Programming Setup
(EDIT SETUP)
Value:
Factory Setup (FACTORY SETUP)
[0]
Setup 1 (SETUP 1)
[1]
Setup 2 (SETUP 2)
[2]
Setup 3 (SETUP 3)
[3]
Setup 4 (SETUP 4)
[4]
✭Active Setup (ACTIVE SETUP)
[5]
Function:
The choice is of the Setup in which programming
(change of data) is to occur during operation (ap-
plies both via the control panel and via the serial
communication port). It is possible to programme the
4 Setups independently of the Setup selected as the
active Setup (selected in parameter 004).
Description of choice:
The Factory Setup [0] contains the data set at the
works and can be used as a data source if the other
Setups are to be returned to a known state.
Setups 1-4 [1]-[4] are individual Setups which can be
used as required. They can be programmed freely,
regardless of the Setup selected as the active Setup
and thus controlling the functions of the VLT fre-
quency converter.
NB!:
If a general change of data or a copying to
the active Setup is effected, this immediately
affects the functioning of the unit.
006
006 Copying of Setups (SETUP COPY)
Value:
✭No copying (NO COPY)
[0]
Copy to Setup 1 from # (COPY TO SETUP 1)
[1]
Copy to Setup 2 from # (COPY TO SETUP 2)
[2]
Copy to Setup 3 from # (COPY TO SETUP 3)
[3]
Copy to Setup 4 from # (COPY TO SETUP 4)
[4]
Copy to Setup all from # (COPY TO ALL)
[5]
✭ # = the Setup selected in parameter 005
Function:
A copy is made from the Setup selected in parame-
ter 005 to one of the other Setups or to all the other
Setups simultaneously . The setup copying function
does not copy parameters 001, 004, 005, 500 and
501.
Copying is only possible in Stop Mode (motor
stopped on a Stop command).
Description of choice:
The copying starts when the desired copying func-
tion has been entered and confirmed by pressing the
[OK] key.
The display indicates when copying is in progress.
007
007 LCP copy (LCP COPY)
Value:
✭No copying (NO COPY)
[0]
Upload all parameters (UPLOAD ALL PARAM)
[1]
Download all parameters (DOWNLOAD ALL)
[2]
Download power-independent par.
(DOWNLOAD SIZE INDEP.)
[3]
Function:
Parameter 007 is used if it is desired to use the inte-
grated copying function of the control panel. The
control panel is detachable. You can therefore easily
copy parameter value(s) from one VLT to another.
Description of choice:
Select Upload all parameters [1] if all parameter val-
ues are to be transmitted to the control panel.
Select Download all parameters [2] if all transmitted
parameter values are to be copied to the VLT fre-
quency converter on which the control panel has
been mounted.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
