VLT
®
5000 Series
Digital inputs Terminal no. 16 17 18 19 27 29 32 33
parameter 300 301 302 303 304 305 306 307
Value:
No function (NO OPERATION) [0] [0] [0] [0] [0] [0] [0]
Reset (RESET) [1]* [1] [1] [1] [1]
Coasting stop, inverse (COAST INVERSE) [0]*
Reset and coasting stop, inverse (COAST & RESET INVERS) [1]
Quick-stop, inverse (QSTOP INVERSE) [2]
DC-braking, inverse (DCBRAKE INVERSE) [3]
Stop inverse (STOP INVERSE) [2] [2] [4] [2] [2] [2]
Start (START) [1]*
Latched start (LATCHED START) [2]
Reversing (REVERSING) [1]*
Start reversing (START REVERSE) [2]
Only start clockwise, on (ENABLE START FWD.) [3] [3] [3] [3]
Only start anti-clockwise, on (ENABLE START REV) [3] [3] [4] [3]
Jog (JOGGING) [4] [4] [5]* [4] [4]
Preset reference, on (PRESET REF. ON) [5] [5] [5] [5] [5]
Preset reference, lsb (PRESET REF. SEL. LSB) [6] [7] [6]
Preset reference, msb (PRESET REF. MSB) [6] [8] [6]
Freeze reference (FREEZE REFERENCE) [7] [7]* [9] [7] [7]
Freeze output (FREEZE OUTPUT) [8] [8] [10] [8] [8]
Speed up (SPEED UP) [9] [11] [9]
Speed down (SPEED DOWN) [9] [12] [9]
Choice of Setup, lsb (SETUP SELECT LSB) [10] [13] [10]
Choice of Setup, msb (SETUP SELECT MSB) [10] [14] [10]
Choice of Setup, msb/speed up (SETUP MSB/SPEED UP) [11]*
Choice of Setup, lsb/speed down (SETUP LSB/SPEED DOWN) [11]*
Catch-up (CATCH UP) [11] [15] [12]
Slow-down (SLOW DOWN) [11] [16] [12]
Ramp 2 (RAMP 2) [12] [12] [17] [13] [13]
Mains failure inverted (Mains failure inverse) [13] [13] [18] [14] [14]
Pulse reference (PULSE REFERENCE) [23] [28]
1
Pulse feedback (PULSE FEEDBACK) [24]
Encoder feedback input, A (ENCODER INPUT 2A) [25]
Encoder feedback input, B (ENCODER INPUT 2B) [24]
1) If this function is selected for terminal 29, the
same function for terminal 17 will not be valid, even
if it has been selected to be active.
* = factory setting
MG.51.A1.02 - VLT is a registered Danfoss trade mark
