3.2 HOMOGENIZING VALVE
3.2.1 Number of Stages 1
3.2.2 Type of actuator PNEUMATIC
3.2.3 Type of control PNEUMATIC
3.2.4 Homogenizing Valve Type 11,9-30 HP
3.3 DRIVE END
3.3.1 Main Motor (frame size; type) AC180M/4P
3.3.2 Main Motor Power 18,5 kW
3.3.3 RPM Crankshaft 44 MIN
3.3.4 RPM Crankshaft 145 MAX
3.3.5 Drive Type ROSSI REDUCER
3.3.6 Gearbox speed reduction ratio 5
3.4 LUBRICATION
3.4.1 Type FORCED
3.4.2 Lubricating system TP3A GR.1/6,1
3.4.3 Oil Cooling system YES
3.5 MAIN ELECTRICAL CIRCUIT
3.5.1 Number of phases 3
3.5.2 Voltage 400 V
3.5.3 Frequency 50 Hz
3.6 AUX ELECTRICAL CIRCUIT
3.6.1 Number of phases /
3.6.2 Voltage 24DC V
3.6.3 Frequency / Hz
4 OPTIONS
4.1 Suction side pulsation damper /
4.2 Delivery side pulsation damper /
4.3 Feeding pump /
4.4 Inlet pressure gauge /
4.5 Electric Power Board /
4.6 Overpressure Valve in Line / setpoint / Bar /
