14 Sabre Owner’s Guide
Some menus have only one letter to make a selection. For example, you can select English or
metric measurements in the Units menu:
UNITS
ENGLISH
A: CHANGE
Repeatedly pressing the A key toggles the choice between English and metric. When the display
shows what you want, press ENTER to confirm the choice. Press EXIT to go to the previous
menu. Continue to press EXIT until the Main Menu appears. Toggle between MAIN MENU 1
and MAIN MENU 2 by repeatedly pressing one of the arrow keys.
The following table provides specific information about the control pad.
Job control keys
START Starts or resumes a routing job.
PAUSE Temporarily stops router actions; the stopped job may be restarted.
Pause may not take effect immediately.
RESET Stops the job immediately if the router is running, and terminates the
job.
Menu selection keys
A Selects menu choice A.
B Selects menu choice B.
C Selects menu choice C.
Menu control keys
EXIT Returns to the previous menu without recording changes to the
current menu.
PAGE UP
Displays the previous menu.
PAGE DOWN
Displays the next menu.
ENTER Records the menu selection made.
Function keys
TBL Z INT (table init) Allows you to initialize from the table surface for through cutting.
MATL Z INT (material
init)
Allows you to initialize from the material surface for non-through
cutting.
ADJ DEPTH Temporarily adjust the initialization depth of the current tool.
Z UP Raises the tool to its maximum height. (0,0)
RPM Sets spindle speed (High Frequency Spindle Option only).
FEED (feed rate) Overrides the X,Y feed rate set in ART Path.
HOME Returns to or changes the job home position.
RET 0,0 Moves the tool to the table orientation point (lower left).
ATC Opens the Automatic Tool Changer menu.
DFLT (default
configuration)
Returns to the factory default settings.
SHIFT Press SHIFT and EXIT during manual routing to turn off the motor
and raise the tool.
