Gerber Sabre User Manual

Getting Started 29
To choose the Surface Reference in ART Path
1
Choose a tool path to generate.
2
In the Tool Path Info dialog box, turn on Table or Material in the Surface Reference
box.
3
Click Generate to process the tool path with the selected Surface Reference.
Verifying surface reference at the Sabre
You can verify the surface reference downloaded from ART Path through the Configuration
Menu 3 of the Sabre control pad. In the event that you have chosen the incorrect surface
reference when generating the tool path in Art Path, you can change the surface reference for
the current tool path. A change in surface reference from the Sabre key pad affects only the
current tool path. ART Path updates the surface reference point for all other tool paths during
processing.
To verify the surface reference
1
Starting at the Status menu, press the down arrow key until you see:
MAIN MENU 2
A: Position control
B: Manual feed
C: Configuration
2
Press C to select the Configuration menu. Press the down arrow key until you see:
CONFIGURATION 3
A: Unused
B: Surface Reference
C: Set to Default
3
Press B to select the Surface Reference menu. The control pad displays:
SURFACE REFERENCE SURFACE REFERENCE
Table (Nominal) Material (Actual)
A: Change OR A: Change
Nom: 0.500 Act: 0.489 Nom: 0.500 Act: 0.489
4
If surface reference is incorrect, press A to change to Table or Material reference.
5
Press ENTER to accept the change.
