Gerber Sabre User Manual

70 Sabre Owner’s Guide
Specifications
Specification Sabre 404 Sabre 408
Active cutting area 54"x 54"
(1370 mm x 1370 mm)
54" x 100"
1370 mm x 2540 mm
Overall size 69" x 75"
(1750 mm x 1900 mm)
69" x 123"
(1750 mm x 3120 mm)
Weight 750 lb. (340 Kg) 1,000 lb. (453 Kg)
Maximum material
thickness
4.4" (110 mm) 4.4" (110 mm)
Maximum material width 59" (1500 mm) 59" (1500 mm)
Z axis travel 7.5" (190 mm) 7.5" (190 mm)
X,Y feed rate 600 ipm (250 mm/sec) 600 ipm (250 mm/sec)
Z feed rate 300 ipm (125 mm/sec) 300 ipm (125 mm/sec)
Maximum positioning rate* 1300 ipm (590 mm/sec) 1300 ipm (590 mm/sec)
Resolution 0.000078" (0.0019 mm) 0.000078" (0.0019 mm)
Drive system Anti-backlash lead screw Anti-backlash lead screw
Controller/motors 32-bit servo 32-bit servo
*At nominal power
