20 Sabre Owner’s Guide
Setting start delay
The start delay is the time the Sabre waits to begin cutting after the router motor is turned on.
This delay allows the motor to achieve the desired speed before cutting. The default is four
seconds.
To set the start delay
1
Press the down arrow key until you see:
MAIN MENU 2
A: Position control
B: Manual feed
C: Configuration
2
Press C to select the Configuration menu. Press down until you see:
CONFIGURATION 2
A: Testing
B: Setup
C: ATC Menus
3
Press B to select the Setup menu. Press down until you see:
SETUP MENU 1
A: Select machine
B: Spindle/Router
C: Start delay
4
Press C to select Start delay menu shown below.
START DELAY
04 seconds
A: Increase
B: Decrease
5
Press A or B to change the rate, then press ENTER to choose the rate. Press EXIT
repeatedly until the STATUS message appears.
Selecting the job data type
Job data type is reached from Setup Menu 3 and is used to switch between G Code (EIA RS-274-
D) jobs and Gerber (ART Path) jobs. It is not recommended that you change job data type from
Gerber unless you are familiar with G-Code data type. For detailed information on using
G Code jobs, see the document
Sabre Router G Code Information
(Gerber part number P71171A).
To select job data type
1
Starting at the Status menu, press the down arrow key until you see:
MAIN MENU 2
A: Position control
B: Manual feed
C: Configuration
2
Press C to select the Configuration menu. Press the down arrow key until you see:
CONFIGURATION 2
A: Testing
B: Setup
C: ATC Menus
