Error Messages
The following chart contains Sabre error message, possible causes, and suggested remedies. If
you need additional assistance, contact your Gerber distributor or the Gerber Router Technical
Support Group at
860-528-1028.
Error Cause Remedy
“ATC AIR PRESSURE”
Air pressure drops below
(approximately) 85 psi at
sensor.
Faulty pressure sensor
Boost air pressure greater
than 100 psi as indicated on
gage.
Replace pressure sensor.
“ATC ARM: arm sensor
failure (both on)”
ATC ‘arm out’ sensor and ‘arm
in’ sensor are both active.
Check sensors and wiring.
“ATC ARM: between
MOVE IT OUT BY HAND”
ATC arm is stopped without
fully extending or retracting.
Disable ATC, then move
arm off table manually.
Check air connections.
Check sensors and wiring.
Check Mechanical
connections for air cylinder
and ‘shock absorber’.
“ATC ARM: in table
MOVE IT OUT BY HAND”
ATC arm is stopped without
fully retracting.
Disable ATC, then move
arm off table manually.
Check air connections at
ATC arm.
Check sensors and wiring.
Check Mechanical
connections for air cylinder
and ‘shock absorber’.
“ATC SPINDLE ON”
Attempt to turn spindle ON
with no tool.
Install tool before turning
spindle on.
Check Clamp
sensor/wiring.
Check Tool presence
sensor/wiring.
“BAD TABLE INIT”
Material surface is below table
surface.
Re-initialize tool with Table
Init.
“CAN'T FIND THE ATC DISK
HOME LOCATION”
ATC position 1 sensor did not
get activated after attempting
to rotate 11 tool positions.
Check sensors and wiring.
