4
Use
Using the camera
80 / 116
Maquet PowerLED II
IFU 01811 EN 10
Using the E-Pan Tilt function
1. Press the E-Pan button 16 to access the function settings page.
2. Define the area to display using the directional keys 18 or the grey keypad 19. You can re-
turn to the centre of the image at any time by pressing the symbol in the centre of the direc-
tional keys 18.
20
21
22
Fig.99: Contrast adjustment
Adjusting the contrast
1. Press the Contrast button 20 to access the contrast adjustment menu.
2. Press the Increase contrast 21 or Decrease contrast buttons 22 to select one of the three
contrast levels.
23
24
25
26
27
Fig.100: White balance
Adjusting the white balance automatically
1. Press the White Balance button 23.
2. Press the Automatic balance button 24 to set the white balance automatically or the
Artificial light button 25 to set the white balance to 3200K or the Daylight button 26 to set
the white balance to 5800K.
Ø The selected button is lit blue and the white balance is applied.
Adjusting the white balance manually
1. Press the White Balance button 23.
2. Place a uniform white surface under the camera.
