GigaBlue hd quad plus - Installation; TV Devices RCA; Component

To Next Page

To Previous Page

Installation

TV Devices RCA / Component

If the GigaBlue box on Audio / Video (also called RCA) want to connect or the Component

connection follow the graph shown below. The individual connectors are color-coded on both

TV and the GigaBlue box. Note that if you use Component for connecting an additional

opportunity for the audio connection must be used.

Yv Pb Pr TV connections

TV connections

Video

Audio R

Audio L
