P a g e | 103
GWN7000 User Manual
Version 1.0.6.28
Figure 62: Branch Office IPSec Phase 1 Configuration
Table 33: IPSec Phase 1 Parameters
Field
Description
Enabled
Enable or Disable the IPSec tunnel.
VPN Name
VPN Connection Name.
Remote Address
Enter the IP address of the remote side of the tunnel.
Interface
Select from which interface the router will try to build the VPN
connection.
IKE Version
Allows the use to choose between using IKE version 1 or 2.
Default value: IKEv1
IKE Lifetime
Specifies in seconds the lifetime of the keying channel.
Default: 3600 seconds.
Key Exchange mode
Select which mode to use for key exchange during the stage of
channel establishment: Main mode or Aggressive mode.
Pre-Shared key
Enter the PSK password for authentication.
