P a g e | 88

GWN7000 User Manual

Version 1.0.6.28

Figure 54: OpenVPN®

OpenVPN® Client configuration

The GWN7000 act as both, an OpenVPN® client and server, once users and client certificate created,

navigate under “VPN → OpenVPN®→ Client” and follow steps below:

1. Click on and the following window will pop up.
