Figure 53: Create OpenVPN® Server

Table 28: OpenVPN® Server

Field

Description

Enable

Click on the checkbox in order to enable the OpenVPN® server

feature.

VPN Name

Enter a name for the OpenVPN® server.

Server Mode

Choose the server mode the OpenVPN® server will operate with.

4 modes are available:
