Grandstream Networks GWN7000 User Manual

P a g e | 47
GWN7000 User Manual
Version 1.0.6.28
Table 19: IPv6 Static Routes
Name
Enter the Name of the static route to be configured.
Enable
Select whether to enable or disable this static route.
Interface
Choose the LAN network or WAN port, which will be using this static route.
Target Network/Host
Enter the Network/Host IP address on which to route the traffic to.
2001:db8:3c4d:4::/64
NextHop
Enter the Gateway’s IP address.
fec0:470:28:5b2::1/64
Metric
Set the metric value. The valid range is 0-255. Default value is 1.
To check the routing table of the router, go under the Routes tab which displays all routes learned by the
router.
Figure 18: Routes

Grandstream Networks GWN7000 Specifications

General

Brand	Grandstream Networks
Model	GWN7000
Category	Network Router
Language	English
